| Brand Name: | XCMG |
| Model Number: | XGC350 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
The connection between the boom and turntable, frame and track beam, and counterweight tray and turntable are all connected by power pins driven by cylinders. The mast lifting cylinder, outrigger cylinder, and track tensioning cylinder make installation and disassembly more convenient. The control room is equipped with cylinders to enable vertical flipping and horizontal rotation.
The ergonomically designed leopard-head-shaped control room features a wide field of vision, comfortable operation, and an aesthetically pleasing appearance.
The box-type radial frame structure is welded with high-strength steel plates, offering excellent overall rigidity and high strength.
The crawler travel system consists of left and right crawler assemblies, each comprising:
17 working conditions across five categories, each providing specific lifting performance based on turntable counterweight combinations:
| No. | Working condition category | Working condition code | Description |
|---|---|---|---|
| 1 | Main boom working condition 【HB(S)】 | HB/1 | Main boom and main hook lifting without arm end pulley |
| 2 | HBS/1 | Main boom and main hook with arm end pulley and auxiliary hook for hoisting | |
| 3 | HBS/2 | Boom end pulley auxiliary hook hoisting with main boom main hook | |
| 4 | Light main boom working condition 【LB(S)】 | LB/1 | Lightweight main boom and main hook hoisting without arm end pulley |
| 5 | LBS/1 | Lightweight main boom hook with arm end pulley auxiliary hook for lifting load | |
| 6 | LBS/2 | Boom end pulley auxiliary hook hoisting with light main boom main hook | |
| 7 | Tower Condition 【H(B)W(S)】 | HW/1 | Tower boom main hook hoisting without main boom pulley block and tower boom single pulley |
| 8 | HWS/3 | No main boom pulley block with tower boom main hook single pulley third hook hoisting | |
| 9 | HWS/1 | Tower boom main hook hoisting without main boom pulley block and tower boom single pulley third hook | |
| 10 | HBW/3 | Single pulley without tower arm and main arm hook of tower arm third hook hoisting | |
| 11 | HBW/1 | Main boom and main hook hoisting with single pulley without tower arm and third hook of tower arm | |
| 12 | Fixed jib working condition 【H(B)F】 | HF/1 | Fixed jib main hook hoisting without main arm pulley block |
| 13 | HBF/2 | Main boom pulley block with main boom main hook empty hook auxiliary arm auxiliary hook hoisting | |
| 14 | HBF/1 | Main boom and main hook hoisting with main boom pulley block fixing auxiliary boom empty hook | |
| 15 | Shield working conditions 【TBF】 | TBF/1 | The main boom and main hook of the shield machine are hoisted with the auxiliary hook of the shield machine empty |
| 16 | TBF/2 | The auxiliary hook of the shield arm is hoisted with the main hook of the main arm empty | |
| 17 | TBF | Double hook composite lifting load with main and auxiliary hooks |
The hydraulic proportional pilot control system features load-independent flow distribution for precise speed control and sensitive operation. The main valve enables compound operation of multiple actions with compact structure and easy maintenance.
The main and auxiliary hoists utilize double-pump configuration for efficient high/low speed control. Dedicated rotary buffer oil circuit ensures smooth start/stop operation, meeting micro-motion and fine lifting requirements.
Comprehensive system includes:
System components:
Consists of vehicle body counterweight (50t) and turntable counterweight (standard 130t, optional 135t).
| Hook Name | 260t | 160t | 16t |
|---|---|---|---|
| Weight(t) | 4.6 | 3.9 | 0.9 |
