| Brand Name: | XCMG |
| Model Number: | XGC200 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
High-strength tension plate structure with high safety factor; can be transported with the boom for easy installation, labor-saving and efficient operation.
Box-shaped double-limb structure with excellent overall stability. Mast can be lifted up and lowered by the mast lifting cylinder.
Key load-bearing structure connecting upper and lower vehicles, featuring a double-sided "I" beam box frame composite structure welded from high-strength steel plates. Connects to lower vehicle through slewing bearing with high strength and stability. Accommodates cab, luffing mechanism, engine system, main pump, hydraulic valve, mast, main arm bottom section, and upper vehicle counterweight.
| No. | Mechanism Name | Usage | Layout Location |
|---|---|---|---|
| 1 | Main lifting mechanism | Main boom operation | Near the turntable slewing center |
| 2 | Auxiliary lifting mechanism | Fixed jib, single pulley lifting operation | Lower part of main boom (forward) |
| 3 | Luffing mechanism | Main boom luffing | Center and rear of turntable |
| 4 | Slewing mechanism | Crane slewing | Front of turntable |
| 5 | Traveling mechanism | Machine traveling | Crawler drive wheel |
Motor-driven planetary gear reducer system lifts main/auxiliary hooks via drum and pulley set. Features built-in planetary reducer and normally closed "spring brake/hydraulic release" system for safety. Uses high breaking force wire rope (φ26mm diameter).
Motor-driven planetary gear reducer achieves main arm luffing through drum and pulley set. Includes built-in planetary reducer with normally closed brake system and ratchet locking device (hydraulic cylinder driven) for multiple protection. Uses φ26mm high breaking force wire rope.
Internal meshing drive with slewing bearing enables 360° rotation. Features built-in planetary reducer with normally closed brake system and mechanical slewing locking device for enhanced safety. Includes free sliding function.
Engineered for large load-bearing capacity, minimal slewing resistance, wear resistance and extended service life.
Power pin connections (oil cylinder driven) between boom/turntable, frame/track beam, and counterweight tray/turntable. Includes mast lifting, outrigger, and track tensioning cylinders for convenient installation. Control room features oil cylinders for vertical flipping and horizontal rotation.
Bionic design provides wide field of vision and comfortable, convenient operation.
Box-type radial structure welded from high-strength steel plates delivers excellent overall rigidity and strength.
