| Brand Name: | XCMG |
| Model Number: | XLC260 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
| Project | Unit | Value |
|---|---|---|
| Max rated lifting capacity | ||
| Main boom working condition | t | 260 |
| Tower jib working condition | t | 100 |
| Fixed jib working condition | t | 100 |
| Max lifting moment | t.m | 1430 |
| Size parameters | ||
| Main boom length | m | 23～86 |
| Tower jib length (optional) | m | 18～63 |
| Fixed jib length (optional) | m | 9～30 |
| Speed Parameters | ||
| Max lifting speed of single rope | m/min | 130 |
| Max single rope speed of main boom luffing | m/min | 2×47 |
| Max slewing speed | m/min | 130 |
| Maximum traveling speed | rpm | 1.0 |
| Rated Power | km/h | 1.0 |
| Engine | ||
| Emission standards | kW | 243 |
| Machine weight (based on 23m basic boom, 260t hook) | t | 224.7 |
| Average ground pressure | MPa | 0.12 |
| Gradeability | - | 30% |
| Max mass of a disassembled piece in transport state | t | 35.4 |
| Max single piece transport dimensions (length x width x height) | m | 10.7×3.0×3.3 |
| Name and quantity | Main boom bottom section 9m | Main boom intermediate section 3mA | Main boom intermediate section 6mA | Main boom intermediate section 12mA | Main boom intermediate section 6m | Main boom intermediate section 3mB | Main boom intermediate section 6mB | Main boom intermediate section 12mB | Main boom top section 5m |
|---|
| Name and quantity | Main boom bottom section 9m | Main boom intermediate section 3mA | Main boom intermediate section 6mA | Main boom intermediate section 12mA | Main boom transition section 6m | Main boom intermediate section 3mB | Main boom intermediate section 6mB | Main boom intermediate section 12mB | Main boom top section 5m |
|---|
