| Brand Name: | XCMG |
| Model Number: | XLC220 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
| Operating radius(m) | 56 | 59 | 62 | 65 | 68 | 71* | 74* | 77* | 80* |
|---|---|---|---|---|---|---|---|---|---|
| 10 | 81 | 79.2 | 77.5 | 68.5 | |||||
| 12 | 66.4 | 65.1 | 63.8 | 62.6 | 61.3 | 60.3 | 59 | 55 | |
| 14 | 55.9 | 54.9 | 53.9 | 52.9 | 51.9 | 51.1 | 50 | 49.3 | 48.3 |
| 16 | 48 | 47.2 | 46.4 | 45.5 | 44.7 | 44 | 43.1 | 42.5 | 41.7 |
| 18 | 41 | 40.8 | 40.4 | 39.7 | 39 | 38.4 | 37.7 | 37.2 | 36.5 |
| 20 | 35.2 | 35 | 34.9 | 34.7 | 34.4 | 33.9 | 33.2 | 32.8 | 32.2 |
| 22 | 30.7 | 30.5 | 30.3 | 30.1 | 29.9 | 29.9 | 29.5 | 29.2 | 28.6 |
| 24 | 27 | 26.8 | 26.6 | 26.5 | 26.2 | 26.2 | 25.9 | 25.9 | 25.6 |
| 26 | 24 | 23.8 | 23.6 | 23.4 | 23.2 | 23.1 | 22.8 | 22.8 | 22.6 |
| 28 | 21.4 | 21.2 | 21.1 | 20.9 | 20.6 | 20.6 | 20.3 | 20.3 | 20 |
| 30 | 19.2 | 19.1 | 18.9 | 18.7 | 18.5 | 18.4 | 18.1 | 18.1 | 17.8 |
| 32 | 17.4 | 17.2 | 17 | 16.8 | 16.6 | 16.5 | 16.2 | 16.2 | 16 |
| 34 | 15.7 | 15.6 | 15.4 | 15.2 | 14.9 | 14.9 | 14.6 | 14.6 | 14.3 |
| 36 | 14.3 | 14.1 | 13.9 | 13.7 | 13.5 | 13.4 | 13.1 | 13.1 | 12.9 |
| 38 | 13 | 12.8 | 12.7 | 12.5 | 12.2 | 12.1 | 11.9 | 11.9 | 11.6 |
| 40 | 11.9 | 11.7 | 11.5 | 11.3 | 11.1 | 11 | 10.7 | 10.7 | 10.5 |
| 42 | 10.8 | 10.7 | 10.5 | 10.3 | 10.1 | 10 | 9.7 | 9.7 | 9.5 |
| 44 | 9.9 | 9.8 | 9.6 | 9.4 | 9.1 | 9.1 | 8.8 | 8.8 | 8.5 |
| 46 | 9.1 | 8.9 | 8.7 | 8.5 | 8.3 | 8.2 | 7.9 | 7.9 | 7.7 |
| 48 | 8.1 | 7.9 | 7.8 | 7.5 | 7.4 | 7.2 | 7.2 | 6.9 | |
| 50 | 7.4 | 7.2 | 7.1 | 6.8 | 6.7 | 6.5 | 6.5 | 6.2 | |
| 52 | 6.6 | 6.4 | 6.2 | 6.1 | 5.8 | 5.8 | 5.6 | ||
| 54 | 5.8 | 5.6 | 5.5 | 5.2 | 5.2 | 5 | |||
| 56 | 5 | 4.9 | 4.7 | 4.7 | 4.4 | ||||
| 58 | 4.5 | 4.4 | 4.2 | 4.2 | 3.9 | ||||
| 60 | 3.9 | 3.7 | 3.7 | 3.4 | |||||
| 62 | 3.2 | 3.2 | 3 | ||||||
| 64 | 2.8 | 2.6 | |||||||
| 66 | 2.4 | 2.1 | |||||||
| Magnification | 7 | 6 | 6 | 6 | 6 | 5 | 5 | 4 | 4 |
