| Brand Name: | XCMG |
| Model Number: | XLC220 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
| Max Rated Lifting Capacity | ||
|---|---|---|
| Main boom working condition | t | 220 |
| Tower jib working condition | t | 80 |
| Fixed jib working condition | t | 75 |
| Max lifting moment | t.m | 1239 |
| Size Parameters | ||
| Main boom length | m | 17～83 |
| Tower jib length (optional) | m | 18～63 |
| Fixed jib length (optional) | m | 9～30 |
| Speed Parameters | ||
| Max lifting speed of single rope | m/min | 120 |
| Max single rope speed of main boom luffing | m/min | 2×34 |
| Max slewing speed | m/min | 120 |
| Maximum traveling speed | rpm | 1.4 |
| Rated Power | km/h | 1.1 |
| Engine | ||
| Emission standards | kW | 243 |
| Max lifting speed of single rope | - | Non-road countryⅢ |
| Machine weight (based on 17m basic boom, 160t hook) | t | 191 |
| Average ground pressure | MPa | 0.11 |
| Gradeability | - | 30% |
| Max mass of a disassembled piece in transport state | t | 32.9 |
| Max single piece transport dimensions (length × width × height) | m | 9.9×3.0×3.3 |
