| Brand Name: | XCMG |
| Model Number: | XGC55 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
| No. | Name | Model/Specifications |
|---|---|---|
| 1 | Engine System |
Engine (Made in China)
Rated power: 155kW/2000 rpm
Max Torque: 930N.m/1300-1500rpm
|
| 2 | Hydraulic System |
Main winch
Reel: Pitch 21.2, Rope capacity 250m
Reducer: Max displacement 80ml/r, Rated pressure 35MPa
Motor: Speed Ratio 50.52, Max output torque 16732N.m
Balance valve: Max flow 350L/min, Max pressure 35MPa
Auxiliary winch
Reel: Pitch 21.2, Rope capacity 250m
Motor: Max displacement 80ml/r, Rated pressure 35MPa
Reducer: Speed Ratio 50.52, Max output torque 16732N.m
Balance valve: Max flow 350L/min, Max pressure 35MPa
Luffing winch
Reel: Pitch 21.2, Rope capacity 100m
Motor: Max displacement 80ml/r, Rated pressure 35MPa
Reducer: Speed Ratio 50.52, Max output torque 17314N.m
Balance valve: Max flow 350L/min, Max pressure 35MPa
Slewing
Motor: Rated displacement 63ml/r, Rated pressure 35MPa
Reducer: Speed Ratio 117.55, Max output torque 22805N.m
Traveling
Motor: Displacement 107ml/r, Rated pressure 35MPa
Reducer: Mmax 80000Nm
Pump Group
Main pump: Max displacement 107ml/r, Rated pressure 35MPa
Valve Group
Main valve: Max flow 400L/min, Rated pressure 35MPa
|
| 3 | Electrical System | Torque limiter |
| 4 | Slewing system | Slewing bearing |
| 5 | Crawler traveling device |
Drive wheel: 2
Guide wheel: 2
Drag chain wheel assembly: 4
Idler wheel: 20
Track plate: 122
|
