| Brand Name: | XCMG |
| Model Number: | XGC350 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
| Project | Unit | Value |
|---|---|---|
| Max rated lifting capacity | ||
| Main boom working condition | t | 350 |
| Light arm working condition | t | 100 |
| Tower jib working condition | t | 148 |
| Fixed jib working condition | t | 145 |
| Shield working condition (main and auxiliary hooks jointly hoisted) | t | 221.7 |
| Max lifting moment | t.m | 2400 |
| Size parameters | ||
| Main boom length | m | 24～66(Optional 96) |
| Lightweight arm length | m | 73.5～97.5(Optional 115.5) |
| Tower jib length | m | 24～42(Optional 66) |
| Fixed jib length (optional) | m | 9(Optional 12) |
| Speed Parameters | ||
| Maximum single rope lifting speed | m/min | 120 |
| Maximum single rope speed of main boom luffing | m/min | 2×42 |
| Maximum single rope speed of tower arm luffing | m/min | 120 |
| Max slewing speed | rpm | 1.0 |
| Maximum traveling speed | km/h | 1.0 |
| Engine | ||
| Rated Power | kW | 338 |
| Emission standards | - | - |
| Machine weight(Based on 24m main boom, 260t hook, 90t+50t counterweight) | t | 280 |
| Average ground pressure | MPa | 0.153 |
| Gradeability | 30% | |
| Max mass of a disassembled piece in transport state | t | 37.5 |
| Max single piece transport dimensions (length x width x height) | m | 11.50×3.00×3.30 |
| Configuration hook type | t | 260t,160t,16t |
