| Brand Name: | XCMG |
| Model Number: | XGC150 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
| No. | Name |
|---|---|
| 1 | Engine |
| 2 | Hydraulic system Main winch | Reducer | Motor Auxiliary winch | Reducer | Motor Luffing winch | Reducer | Motor Slewing | Motor | Reducer Traveling | Motor | Reducer Main pump Main valve |
| 3 | Electrical System | Torque limiter |
| 4 | Slewing bearing |
| 5 | Hook |
| Project | Unit | Value |
|---|---|---|
| Max rated lifting capacity | ||
| Main boom working condition | t | 150 |
| Fixed jib working condition | t | 22 |
| Single pulley at arm end working condition | t | 13 |
| Max lifting moment | t.m | 790.8 |
| Size parameters | ||
| Main boom length | m | 16～76 |
| Fixed jib length | m | 13～31 |
| Single pulley at arm end condition | m | 1.4 |
| Speed Parameters | ||
| Max lifting speed of single rope(No load, fifth floor) | m/min | 120 |
| Max single rope speed of main boom luffing(No load, third floor) | m/min | 2×50 |
| Max slewing speed | rpm | 1.5 |
| Maximum traveling speed | km/h | 1.3 |
| Engine | ||
| Rated Power | kW | 200 |
| Emission standards | -- | - |
| Machine weight (based on 16m basic boom, 150t hook) | t | 130 |
| Average ground pressure | MPa | 0.092 |
| Gradeability | -- | 30% |
| Max single piece shipping weight | t | 29 |
| Max single piece transport dimensions (length x width x height) | m | 9.32×3×3.3 |
