| Brand Name: | XCMG |
| Model Number: | XGC85 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
| Project | Unit | Value |
|---|---|---|
| Max rated lifting capacity | ||
| Main boom working condition | t | 85 |
| Single pulley at arm end working condition | t | 8 |
| Fixed jib working condition(Without main hook) | t | 12 |
| Max lifting moment | ||
| Main boom working condition | t.m | 341 |
| Fixed jib working condition | t.m | 196.4 |
| Single pulley at arm end working condition | t.m | 191.8 |
| Size parameters | ||
| Main boom length | m | 13～58 |
| Main boom luffing angle | ° | -3～80 |
| Fixed jib length | m | 7～19 |
| Angle between main boom and fixed jib | ° | 10,30 |
| Single pulley at arm end | m | 1.4 |
| Speed Parameters | ||
| Max single rope speed of hoisting mechanism | m/min | 120 |
| Max single rope speed of main boom luffing mechanism | m/min | 70 |
| Max slewing speed | rpm | 2.0 |
| Max traveling speed | km/h | 0.9 |
| Engine | ||
| Engine Model | - | SC9D272G2 |
| Engine rated power and speed | kW/rpm | 200/1800 |
| Emission standards | - | - |
| Machine weight (based on 13m basic boom, 85t hook) | t | 71.5 |
| Average ground pressure | MPa | 0.087 |
| Gradeability | - | 30% |
| Max single piece shipping weight | t | 41.2 |
| Maximum dimensions of a single piece (turntable) in transport state (length × width × height) | m | 13.05×3.4×3.3 |
