96m Boom 650T Crawler Crane SCC6500 650 Ton Crawler Crane SANY

96m Boom 650T Crawler Crane SCC6500 650 Ton Crawler Crane SANY

96m Boom 650T Crawler Crane SCC6500 650 Ton Crawler Crane SANY

Brand Name: SANY
Model Number: SCC6500
MOQ: One Crane
Price: 200,000-6,000,000 RMB per unit
Payment Terms: L/C,T/T
Supply Ability: Supply According to Customer Needs
Detail Information
Product Description
Detail Information
Place of Origin:
China
Gradeability:
30%
Operating Weight:
650 Tons
Max Lifting Height:
120 Meters
Slewing Speed:
1.5 Rpm
Max Line Speed:
120 M/min
Travel Speed:
1.5 Km/h
Engine Power:
298 KW
Max Lifting Capacity:
650 Tons
Max Line Pull:
650 KN
Boom Length:
18-96 Meters
Counterweight:
150 Tons
Jib Length:
18-96 Meters
Packaging Details:
Packing According to Customer Requirements
Highlight:

96m Boom 650T Crawler Crane

,

650T Crawler Crane SCC6500

,

SCC6500 650 Ton Crawler Crane

Product Description
Safety Challenges 650T Crawler Crane / Long Boom Crane Jib Length 18-96 Meters
650T Crawler Crane Solves Urban Safety Challenges
The SCC6500 crawler crane is engineered to address the complex safety requirements of urban construction environments with its advanced design and robust performance capabilities.
SCC6500 Crawler Crane Technical Specifications
Undercarriage System
  • Travel Drive: Dual-speed system with strong traction, capable of 70% load-carrying steering. Independent reducers enable flexible forward, backward, and on-the-spot steering.
  • Travel Brake: Normally closed brake system located inside the reducer with automatic compensation, requiring no adjustment. Brake releases automatically when travel handle is engaged.
  • Track Shoes: 136 total track shoes (1500mm width each) with hydraulic tension adjustment via jacks and gasket positioning for optimal tension.
  • Base Frame: High-strength welded structure with hydraulic cylinder-driven power pin connection for easy installation and disassembly.
  • Traveling Speed: Variable speed motor provides two ranges (0-1.0km/h high speed, 0-0.55km/h low speed) with infinite speed variation within each range for smooth operation.
Operating Equipment
Constructed with high-strength steel pipes for all operating mechanisms, high-strength steel plates, and luffing supports. All pulleys feature rolled and welded construction - boom pulleys and hook pulleys are uniformly durable.
Boom Structure
  • Space truss design with uniform middle section and variable end sections
  • Welded steel pipe construction with reinforced steel plates at top and root for optimal load transmission
  • Main boom length ranges from basic 24m configuration to maximum 108m extension
Boom Composition
Component Specification
Lower Boom 12m × 1
Transition Boom 10.5m × 1
Connecting Section 1.5m × 1
Intermediate Boom (6m) 6m × 2
Intermediate Boom (12m) 12m × 6
