| Brand Name: | SANY |
| Model Number: | SCC6500 |
| MOQ: | One Crane |
| Price: | 200,000-6,000,000 RMB per unit |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Supply According to Customer Needs |
Features folding drum design with hydraulic motor drive through planetary reducer, enabling multiple compound actions and excellent micro-speed performance.
| Main Lifting Mechanism | ||
|---|---|---|
| Roll diameter | 630mm | |
| Outermost working layer rope speed | (0~48)×2m/min | |
| Wire rope diameter | 28mm | |
| Main luffing wire rope length | 715m | |
| Auxiliary Lifting Mechanism | ||
|---|---|---|
| Roll diameter | 630mm | |
| Outermost working layer rope speed | 0~105m/min | |
| Wire rope diameter | 28mm | |
| Auxiliary luffing wire rope length | 960m | |
| Super-shifting Mechanism | ||
|---|---|---|
| Roll diameter | 630mm | |
| Outermost working layer rope speed | 0~120m/min | |
| Wire rope diameter | 28mm | |
| Super lifting luffing wire rope length | 1020m | |
Dual motor drive system with planetary reducers provides 360° rotation capability. Features two-speed gear selection (0.6rpm and 1.2rpm) with stepless speed regulation for smooth operation. Utilizes three-row roller type external gear slewing bearing.
Fully sealed steel frame structure with tempered glass and GE structural panels. Features include:
Advanced operator interface with comprehensive monitoring:
