Products

Home / Products / 650T Crawler Crane /

Construction 650T Crawler Crane 895 KW Engine Power / Mobile Crawler Crane

Name: Construction 650T Crawler Crane 895 KW Engine Power / Mobile Crawler Crane
Brand: Shandong Tengfei Hoisting Engineering Co., Ltd.
SKU: SCC6500
Price: 103.00 USD
Availability: InStock

Brand Name:	SANY
Model Number:	SCC6500
MOQ:	One Crane
Price:	200,000-6,000,000 RMB per unit
Payment Terms:	L/C,T/T
Supply Ability:	Supply According to Customer Needs

Detail Information

Product Description

Detail Information

Place of Origin:

China

Counterweight:

150 Tons

Slewing Speed:

1.5 Rpm

Transport Weight:

650 Tons

Travel Speed:

1.5 Km/h

Max Operating Radius:

8 Meters

Boom Length:

18-96 Meters

Max Wind Speed:

20 M/s

Max Lifting Capacity:

650 Tons

Engine Power:

895 KW

Max Hoist Speed:

120 Meters Per Minute

Max Tip Height:

120 Meters

Max Ground Pressure:

0.9 Kg/cm²

Max Load Moment:

6500 Ton-meters

Max Line Speed:

120 Meters Per Minute

Packaging Details:

Packing According to Customer Requirements

Highlight:

construction 650t crawler crane

construction mobile crawler crane

650 tons 650t crawler crane

Product Description

Construction 650T Crawler Crane 895 KW Engine Power / Mobile Crawler Crane

650T Crawler Crane Is Versatile In Various Construction Scenarios

SCC6500 Crawler Crane Technical Specifications

Detailed Introduction

The upper part

Engine

Eight-cylinder, water-cooled engine with rated power of 400Kw
Rated speed of 2000rpm
Maximum output torque of 2630N*m
Speed at maximum output torque of 1200rpm

Control System

Imported RC controller, encoder, torque limiter, display, intelligent sensor and closed-circuit monitoring system are used. CAN Bus is used for data transmission between the controller, display, operating handle, encoder, engine and torque limiter, which improves the reliability of the system.

Hydraulic system

The hydraulic system includes: lifting hydraulic system, traveling hydraulic system, slewing hydraulic system, luffing hydraulic system, servo hydraulic system, anti-tilt hydraulic system, cooling system, auxiliary hydraulic system, etc. The main hydraulic components are imported hydraulic products.

Features: The main system adopts closed circuit, which is energy-saving, efficient and controllable; starting, stopping and switching are smooth, without impact, fast operation response, low heat generation and long service life. Electric proportional control elements are widely used to facilitate accurate and intelligent control.

Main and auxiliary lifting mechanism

The variable hydraulic motor drives the planetary gear reducer to control the lifting and lowering of the main lift Ⅰ and the main lift Ⅱ. It has good micro-speed performance.

The fastest gear can realize the rapid power lifting of the main lift Ⅰ and the main lift Ⅱ. One lift can be used for lifting weights below 325t, and two lifts must work simultaneously for lifting weights above 325t. The main lift Ⅰ and the main lift Ⅱ have synchronization function. The maximum ratio is 48. The multi-layer winding of the folding drum ensures that the rope is not tangled. The reducer has the characteristics of low noise, high efficiency, long service life and convenient oil change.

Main lifting mechanism
Roll diameter	630mm
Outermost working layer rope speed	0~110m/min
Wire rope diameter	28mm
Main winch wire rope length	1180m
Rated single rope tension	16.4t

Auxiliary lifting mechanism
Roll diameter	630mm
Outermost working layer rope speed	0~105m/min
Wire rope diameter	28mm
Auxiliary winch wire rope length	665m
Rated single rope tension	16.4t
