400T Crawler Mounted Mobile Crane ACC4000A Crawler Crane 400 Ton

400T Crawler Mounted Mobile Crane ACC4000A Crawler Crane 400 Ton

Brand Name: SANY
Model Number: ACC4000A
MOQ: One Crane
Price: 200,000-6,000,000 RMB per unit
Payment Terms: L/C,T/T
Supply Ability: Supply According to Customer Needs
Detail Information
Place of Origin:
China
Operating Weight:
400 Tons
Max Gradeability:
30%
Max Working Radius:
100 Meters
Boom Length:
102 Meters
Max Load Capacity:
400 Tons
Slewing Speed:
0-2.5 Rpm
Max Luffing Jib Length:
84 Meters
Max Luffing Jib Combination:
102 Meters + 84 Meters
Max Lifting Height:
140 Meters
Hoist Speed:
0-120 M/min
Engine Power:
298 KW
Max Travel Speed:
1.5 Km/h
Packaging Details:
Packing According to Customer Requirements
Highlight:

400T Crawler Mounted Mobile Crane

,

Crawler Mounted Mobile Crane ACC4000A

,

ACC4000A Crawler Crane 400 Ton

Product Description
400T Crawler Mounted Mobile Crane For Excavation And Transportation Of Ore And Stone
ACC4000A Crawler Crane Technical Specifications
Overview
Calculation of Rated Load
The rated load in the load table is divided into parts determined by strength and stability. Stability calculations follow ISO 4305:1991 standards, with rated loads always within 75% of tipping capacity.
Correct Use of Load Tables
  • Ground conditions: Rated values assume hard, level ground with <1% slope. Adjust for actual conditions.
  • Actual lifting capacity: Subtract hook, sling, and wire rope weights from rated load.
  • Temperature range: Operational between -20℃ to 40℃.
  • Wind speed: Maximum 9.8m/s (13.8m/s for booms <50m). Higher winds require boom lowering.
  • Working range: Load table values apply to 360° rotation.
  • Hoisting travel: Rated loads apply to stationary operation - reductions required for travel.
Hook Parameters (Single Pulley Block)
Rated Load (t) 320t Lifting Hook 260t Lifting Hook 160t Lifting Hook 50t Lifting Hook 16t Ball Hook
Hook Deadweight (t) 10.2 5.13 3.18 1.7 0.91
Extended Arm Weight (t) 0.4
Note: Wire rope weight from hook to boom head calculated as 3.69kg/m.
Hoisting Travel Guidelines
Capacity varies by condition:
  • Main arm: 100% rated load for straight travel, 70% for walking/turning
  • Fixed/Variable jib: 100% rated load for straight travel
Critical Safety Practices:
  • Minimize travel range with loads
  • Keep loads close to ground (<500mm ideal)
  • Use low gear and prevent load swing
